Features + advantages

  • Transport timber lengths between 2 and 6 metres
  • Very low deadweight
  • Offset frame for extremely low loading height
  • Payload-oriented design and weight-optimised steel construction
  • Twin tyres for maximum stability, whether parked or driving

Vehicle request

Send us your request to receive a personalised offer for this vehicle.
Made in Germany. Since 1878. Many manufacturers talk about quality and a long service life. We actually deliver it.

With each new vehicle generation, we raise the bar a little higher – to achieve things that our competitors have not. True DOLL quality is all about usefulness; it's about satisfaction, being ahead of your game, taking pride in what you do. And it's about reliability and safety. Our quality sets the standard – mile after mile, on any terrain.

Vehicle details and equipment

Facts + components

  • Load securing points integrated into the frame, plus optional bolted points
  • Bulb holders mounted on side of frame
  • Bolsters and stakes available in a range of premium materials
Lightweight for higher payload

A2K-LZ59-L

Weighing in at just 2,800 kg, the incredibly light deadweight of this vehicle is achieved through the use of a special weight-optimised frame in conjunction with light 9 t axles.

Extended load floor

A2K-LZ64

There’s a 50 cm difference between the lightweight A2K-LZ59-L and the A2K-LZ64 with extended load floor. Whichever option you choose, you’re guaranteed to benefit from a low deadweight and maximum robustness.

Flush aluminium cover plates

Countersunk fillister head screws and a flush surface finish make it easy to sweep away any leaves or bark left behind.

Full LED lighting at rear

Optimal illumination thanks to full LED lighting with dynamic indicators and flashing side marker lights. A solution that not only looks great, but boosts road safety too.

All bolsters bolted

For easy servicing and complete flexibility, we don’t weld our bolsters into place. At DOLL, even the first bolster on the drop is bolted.

Technical data
A2K-LZ-64

Dimensions
  • Deadweight: from approx. 3,000 kg
  • Loading height (loaded): approx. 955 mm (with 265/70 R 22.5 tyres)
  • Total length: 8,425 mm (with 900 mm drawbar)
  • Loading length: 6,400 mm
  • Wheelbase: 4,900 mm
Axles and chassis
  • Chassis: 9 t, 10 t or 12 t drum or disc brakes
  • Suspension: pneumatic
Attachment parts and accessories
  • DOLL MAMMUT or ExTe bolsters and stakes
  • Various drawbars
  • Tool boxes
  • A wide range of load securing options
  • A wide range of lighting options
  • Camera systems
  • Various tyre and wheel combinations

Technical data
A2K-LZ-59-L

Dimensions
  • Deadweight: from approx. 2,800 kg
  • Loading height (loaded): approx. 955 mm (with 265/70 R 22.5 tyres)
  • Total length: 7,950 mm (with 1,900 mm drawbar)
  • Loading length: 5,900 mm
  • Wheelbase: 4,400 mm
Axles and chassis
  • Chassis: 9 t, 10 t or 12 t drum or disc brakes
  • Suspension: pneumatic
Attachment parts and accessories
  • DOLL MAMMUT or ExTe bolsters and stakes
  • Various drawbars
  • Tool boxes
  • A wide range of load securing options
  • A wide range of lighting options
  • Camera systems
  • Various tyre and wheel combinations

Performance made easy

The foundations for top performance are laid in our factory. All our vehicles are built in our professional, precise and careful production process. We pay special attention to the stability of the frame and all components, to achieving a perfect finish, and to the long-term strength of our products. We only use high-quality materials – such as long-lasting fine-grained steel – in our production process.
